OEM B4P DIP-M Supplier, Factory

Title:4P DIP-M Gold-plated spring pin Male Female black outer shell direct current. Product Model: 4P DIP-M Housing: PA46+30%GF Barrel: Brass C3604 Plunger: Brass C3604 Spring: SUS304 Barrel: 3u plating gold, nickel base 50~80u' Plunger: 3u plating gold, nickel base 50~80u' Spring: not plated Rated: DC 12V 2A Contact Resistance: 50mΩ Max. Insulation resistance: minimum 1000mΩ Resistance voltage: 500VAC/ min Force: 60g±20% Life: 10000 cycles(min) Withstanding High Temperature: 280℃ Operational Temperature: -40℃~85℃

Send Inquiry

Product Description

⚡

Superior Conductivity: Gold-plated spring pin with low resistance and strong conductivity.

🛡️

Stable Output: Excellent material selection ensures more stable power and signal output.

🔥

High Durability: High quality copper material; reliable, safe, durable, high temperature resistant, and flame retardant.

💪

Impact Resistance: PA46 material connector, designed to be fall and impact resistant.

Wide Range of Applications

⌚ Smart Wearables: Smart watches, bracelets, glasses, Bluetooth headphones, smart gloves, VR devices, etc.

📱 3C Consumer Electronics: Tablet PCs, electronic locks, electric cars, smart water cups, cell phones, and charging data lines.

🏥 Medical Industry: Medical equipment, beauty equipment, hearing aids, blood pressure meters, heart rate monitors, and handheld ECGs.

🤖 Intelligent Devices: Intelligent robots, sensors, handheld devices, drones, and vehicle-mounted devices.

Our focus remains on professional administration, the introduction of talented personnel, and strong team building to improve quality standards and liability consciousness. We have successfully attained international quality certifications including IS9001 and European CE certification.

We provide high-quality solutions for 3 Pin SMT Male Automotive Tab Headers, High Quality USB Male DC Round Magnetic Charging Cables, and Automotive Electrical Connectors. With ISO/TS16949 compliance, we are dedicated to providing excellent technical solutions and reliable product parameters for international trade.

Frequently Asked Questions

What makes these spring pins highly conductive?

The pins use a gold-plated design which ensures low resistance and exceptionally strong conductivity for stable performance.

Are these connectors suitable for high-temperature environments?

Yes, the products are made from high-quality copper and PA46 materials that are both high-temperature resistant and flame retardant.

Can these connectors be used in medical devices?

Absolutely. They are widely used in medical equipment such as blood pressure meters, hearing aids, and handheld electrocardiograms.

What type of charging solutions do you offer?

We specialize in various solutions including USB Male DC round magnetic charging cables and SMT automotive tab headers.

How durable is the connector housing?

The connectors utilize PA46 material, which provides excellent impact and fall resistance, ensuring longevity in demanding environments.

Do these products meet international quality standards?
