China Is a DC socket for power connection DC-019 three pin Manufacturers, Factory

Product model: DC-019 Metal material: Copper Shell material: PPA nylon Current: 1A Voltage: 30V Color: Black Temperature range: -30~70℃ Hole size: Φ2.0Φ2.5 Withstand voltage: AC500V(50Hz) /min Contact resistance: ≤0.03Ω Insulation resistance: ≥100MΩ Inserting and pulling force: 3-20N Life span: 5,000 times

Send Inquiry

Product Description

Product Overview & Key Characteristics

The DC-019 socket is a premier solution for power connection, meticulously designed to meet modern electronic requirements. It stands out in the market due to its exceptional safety standards and structural integrity.

⚖️

Clear Polarity

Designed with distinct positive and negative polarity markings to ensure correct power connection, preventing equipment damage or safety hazards.

🛡️

Safety Protection

Equipped with a built-in fuse system that maintains device safety by automatically cutting off power during overloads or short circuits.

💎

Durable & Reliable

Constructed from high-quality materials with a rugged shell and reliable internal circuitry for long-term stability and performance.

🔧

Easy Installation

Features a user-friendly installation and removal design, allowing for quick integration into devices and easy replacement when needed.

Overall, the DC-019 socket is characterized by clear polarity, safety protection, durability and reliability, and easy installation. It is an excellent power connection product that can meet the power needs of a variety of different types of devices.

Applications & Usage Guide

The DC-019 is widely used in a variety of electronic equipment, such as mobile power supplies, audio equipment, video cameras, and LED light belts. When using the socket, users must determine the positive and negative polarity of the power supply and correctly insert it to supply power to the device.

Because the socket has built-in protection devices such as fuses, when the power is overloaded or short-circuited, the socket can automatically cut off the power supply, thus ensuring the safety of equipment and people. This makes it a highly practical power connection product for a secure and reliable power supply.

Frequently Asked Questions

What are the primary features of the DC-019 socket?

The DC-019 socket features clear polarity identification, built-in safety protection (fuse), high durability with quality materials, and a design that supports easy installation and disassembly.

How does the DC-019 handle power overloads?

The socket is equipped with a built-in fuse. In the event of a power overload or a short circuit, it automatically cuts off the power supply to protect both the device and the user.

What types of devices are compatible with this socket?

It is highly versatile and widely used in mobile power units, audio systems, video cameras, LED light strips, and various other electronic devices.

Is the DC-019 socket difficult to install?

No, it is designed for simplicity. The simple installation and removal design allows users to easily connect or replace the socket according to their specific needs.

Why is clear polarity important for this socket?

Clear polarity ensures that the user connects the power supply correctly. This prevents potential equipment damage and eliminates threats to personal safety caused by reversed connections.

What ensures the long-term stability of the DC-019?

Stability is ensured by the use of high-quality materials for the outer shell and a reliable internal circuit design, making it durable for long-term use.
