Enhanced isolation performance
Up to 3000Vdc signal isolation voltage, effectively isolating input and output signals, so that electrical noise and interference effects are minimized.
Wide input range
Support 4-20mA or 0-20mA analog current signal as input signal, and support linear and reverse input mode.
High precision and stability
The module has a very high precision, the output accuracy can reach 0.1% FS; At the same time, programmable gain and bias correction circuits are integrated to achieve long-term stability.
External power supply
The module uses external power supply and supports DC power input ranging from 9 to 36VDC.
Easy installation
Compact housing size and easy terminal design make the module easy to install and operate.
Industrial automation control system
This module can separate the control signals, isolate the interference and electrical noise between different systems, and improve the stability and accuracy of the control system.
Environmental monitoring system
The module can isolate the signal collected by the sensor, improve the measurement accuracy, and reduce the impact of signal interference and error.
Power system
The module can isolate the current signal and separate the interference and noise between different systems to improve the stability and reliability of the power system.
Transportation industry
The module can isolate the signals collected by vehicle sensors, improve the accuracy and stability of the control system, and thus improve the safety and reliability of vehicles.
Frequently Asked Questions
What is the maximum signal isolation voltage of this module?
The module provides high-performance isolation with a voltage capacity of up to 3000Vdc.
What types of input signals are compatible?
It supports standard 4-20mA or 0-20mA analog current signals and is compatible with both linear and reverse input modes.
How accurate is the signal output?
The module is highly precise, achieving an output accuracy of up to 0.1% FS with integrated correction circuits for stability.
What are the power supply requirements?
The module requires an external DC power supply within the range of 9V to 36VDC.
Is the module difficult to install?
No, it features a compact housing and a user-friendly terminal design for easy installation and operation.
In which industries is this module typically used?
It is widely used in industrial automation, environmental monitoring, power systems, and the transportation industry.
