China GST P4A15 4P1 atching Car Engine Power Switch Power switch and button Switch Self-locking Waterproof Button Manufacturers, Companies
1 / 3
China GST P4A15 4P1 atching Car Engine Power Switch Power switch and button Switch Self-locking Waterproof Button Manufacturers, Companies
Product Model:GST-P4A-1P1
Voltage Resistance: 2000V DC
Insulation resistance: ≥100MΩ
Mechanical life: 20000times
Operating Force：2N～8N
Withstand voltage：1500V 1s no breakdown.
Temperature: -25～+85℃
Relative humidity：≤95%
Rated Voltage：250V AC
Rated Current：4A
Surface Quality: Smooth metal finish without rust or corrosion.
Plating Integrity: Plating ensures no creasing or peeling.
Durability: No cracks, damage, or base deformation.
Metal surface should be smooth and not be corroded by rust. Plating should not crease or peel off. Plastic casing should not be uneven, crude or have any cracks or damage. The insulation of different parts conducting electricity should bear the function of experiment voltage and there are no punctures on it. 90% of the surface will be covered by solder. Without deformation of base, can satisfy mechanical, electronic performance. Action without blocking phenomenon, button allows the wear surface.
Frequently Asked Questions
What are the appearance requirements for the metal surfaces?
The metal surface must be smooth and completely free from rust corrosion. Additionally, any plating must be secure without creasing or peeling.
What quality standards apply to the plastic casing?
The plastic casing should be even and refined, showing no signs of crude manufacturing, cracks, or physical damage.
How is the electrical insulation performance verified?
Insulation of conductive parts must withstand experiment voltage requirements without any punctures or failures.
What is the standard for solder coverage on the surface?
At least 90% of the designated surface area must be covered by solder to ensure proper connectivity.
Does the product maintain its shape under mechanical stress?
Yes, the design ensures there is no deformation of the base, allowing it to satisfy all mechanical and electronic performance specifications.
What is the operational standard for the buttons?
The action must be smooth without any blocking phenomenon. Normal wear on the surface of the button is permitted over time.
