Product Model:8011
Voltage Resistance: 2000V DC
Insulation resistance: ≥100MΩ
Mechanical life: 10000times
Insulation resistance：100MΩ MIN
Temperature: -25~+70 ℃
Relative humidity: ≤ 95%
Rated Voltage: 250V AC
Rated Current: 2.5A
The light is white, the strong range is blue, the weak range is black, and the power supply is brown
Surface Quality
Metal surface should be smooth and not be corroded by rust. Plating should not crease or peel off.
Casing Integrity
Plastic casing should not be uneven, crude or have any cracks or damage.
Insulation Performance
The insulation of different parts conducting electricity should bear the function of experiment voltage and there are no punctures on it.
Soldering & Mechanical
90% of the surface will be covered by solder. Without deformation of base, can satisfy mechanical and electronic performance.
Operational Smoothness
Action without blocking phenomenon; button allows the wear surface.
Frequently Asked Questions
What are the appearance requirements for metal components?
The metal surface must be smooth, free from rust, and the plating must remain intact without creasing or peeling.
How should the plastic casing be inspected?
Plastic casings are inspected for uniformity. They should not be crude, uneven, or show any signs of cracks or structural damage.
What are the safety standards for the insulation parts?
Insulation must withstand the required experiment voltage without any punctures occurring between different conducting parts.
What is the standard for solder coverage on the surface?
At least 90% of the relevant surface area must be effectively covered by solder to ensure connectivity.
Will the base deform under mechanical stress?
The product is designed to satisfy both mechanical and electronic performance requirements without any deformation of the base.
Does the button mechanism experience blocking during use?
No, the mechanism is designed for action without blocking phenomena, though it is engineered to allow for standard surface wear.
