OEM AS150-F Battery Terminal Plug With Lid Supplier, Factories

1 / 1

OEM AS150-F Battery Terminal Plug With Lid Supplier, Factories

Product Model: AS150-F Rated Current: 65A MAX（8AWG△＜85℃）;Pin:1A Voltage Resistance: 600V DC Insulation resistance: ≥2000MΩ Contact resistance: ≤1.0MΩ Mechanical life: 100 times Salt Spray: 48h Protection level: IP40 Operational Temperature: -20℃~120℃ Flame Retardant Rating: UL94 V-2 Outer Hull: PA, BLACK, RED Pinhole: Aldary, Elecreoplate: Gold Plating

Send Inquiry

Product Description

⚙️

AS150-F Product Overview:
AS150-F is a 180° outlet welded assembly type single PIN joint without resistance, widely used in plant protection and other professional fields of UAV.

⚡

Application Compatibility:
It applies to the wire-to-wire connection of lithium batteries, motors, and controllers.

Telecontrolled aircraft Telecar Remote control ship Unicycle

⚠️

When in use, do not exceed the rated current and voltage.

⚠️

Do not use it when external forces are applied to the connector.

⚠️

Do not use it in a place with high temperature and humidity.

⚠️

When opening the package, be careful to prevent deformation, bending, or ejecting of terminals.

Balancing car Electric scooter Twister

Electric vehicle UAV Traversal machine Solar lamp

Q1: What is the main structural feature of the AS150-F? A: It is a 180° outlet welded assembly type single PIN joint designed without resistance for high-efficiency power transmission.

Q2: Which components can the AS150-F connect? A: It is specifically designed for wire-to-wire connections between lithium batteries, motors, and electronic speed controllers.

Q3: Is the AS150-F suitable for professional drones? A: Yes, it is widely utilized in professional fields such as plant protection UAVs and traversal machines.

Q4: What should be avoided during installation? A: Ensure no external forces are applied to the connector during use and handle terminals carefully to prevent bending or deformation.

Q5: Are there any environmental restrictions for using this connector? A: It should not be used in environments with high temperature or extreme humidity to ensure safety and performance.

Q6: Can this connector be used for smaller personal transport devices? A: Yes, it is ideal for unicycles, balancing cars, electric scooters, and twisters.
