China MR30-F Connector Plug With Sheath For Lipo Supplier, Factories

·Product Model: MR30-F ·Rated Current: 20A MAX（16AWG△＜85℃） ·Voltage Resistance: 500V DC ·Insulation resistance: ≥2000MΩ ·Contact resistance: ≤1.2MΩ ·Mechanical life: 100times ·Salt Spray: 48h ·Flame Retardant Rating: UL94 V-0 ·Outer Hull: PA, YELLOW, BLACK ·Pinhole: Aldary，Elecreoplate: Gold Plating ·Protection level: IP40 ·Operational Temperature: -20℃~120℃

Send Inquiry

Product Description

Product Overview & Features

MR30-F is a classic 180° line welded injection molded 3PIN connector, optional rear cover, rectangular arrangement, provides an integrated solution for the longitudinal space PCB board, can be perfectly combined with the motor, integrated, for the current power lithium power plug-in standard parts, the other wired plate design. Apply to the wire-to-wire connection scenario between lithium batteries and controllers.

Electric vehicle UAV Traversal machine Solar lamp

Usage Precautions & Guidelines

--When in use, do not exceed the rated current and voltage.

--Do not use it when external forces are applied to the connector.

--Do not use it in a place with high temperature and humidity.

--When opening the package, be careful to prevent deformation, bending, or ejecting of terminals.

Balancing car Electric scooter Twister

Telecontrolled aircraft Telecar Remote control ship Unicycle

Frequently Asked Questions

Q1: What are the primary applications for the MR30-F connector? A: It is designed for wire-to-wire connections between lithium batteries and controllers, commonly used in UAVs, electric scooters, and solar lamps.

Q2: How does the 180° line welded design benefit PCB layout? A: The 180° design and rectangular arrangement provide an optimized solution for longitudinal space on PCB boards, allowing for better motor integration.

Q3: Can this connector handle extreme environmental conditions? A: It is recommended to avoid using the connector in environments with high temperature and high humidity to ensure long-term reliability.

Q4: What precautions should be taken during electrical operation? A: Users must strictly adhere to the rated current and voltage limits. Exceeding these specifications can lead to connector failure or safety risks.

Q5: Is there an optional rear cover for the MR30-F? A: Yes, the MR30-F features an optional rear cover to meet different assembly and protection requirements.

Q6: What should I check when unpacking the product? A: Be careful during unpacking to prevent terminal deformation, bending, or accidental ejection, which ensures smooth installation.
