China Brass Gold Plated MR60-F Three-core Plug With Sheath Manufacturers, Suppliers
1 / 1
China Brass Gold Plated MR60-F Three-core Plug With Sheath Manufacturers, Suppliers

China Brass Gold Plated MR60-F Three-core Plug With Sheath Manufacturers, Suppliers

Product Model: MR60-F Rated Current: 35A MAX（12AWG△＜85℃） Voltage Resistance: 500V DC Insulation resistance: ≥2000MΩ Contact resistance: ≤1.0MΩ Mechanical life: 100times Salt Spray: 48h Protection level: IP40 Operational Temperature: -20℃~120℃ Flame Retardant Rating: UL94 V-0 Outer Hull: PA, YELLOW Pinhole: Aldary，Elecreoplate: Gold Plating
Send Inquiry

Product Description

1
MR60-M is a classic 180° outbound welding injection molded 3PIN connector, featuring an optional rear cover and rectangular arrangement.
2
Designed as a standard part for power lithium power plug-ins with a wire-to-wire interface.
3
Optimized for wire-to-wire connection scenarios between controllers and lithium batteries.
Application List 1
Electric vehicle | UAV | Traversal machine | Solar lamp
MR60-M Product View 1
MR60-M Product View 2
⚠️ Usage Guidelines & Safety Precautions
!
Do not exceed the rated current and voltage during operation.
!
Ensure no external forces are applied to the connector during use.
!
Avoid environments with high temperature and humidity.
!
Prevent deformation, bending, or ejecting of terminals when opening the package.
Instructional Image 1
Instructional Image 2
Instructional Image 3
Application List 2
Balancing car | Electric scooter | Twister
Application List 3
Telecontrolled aircraft | Telecar | Remote control ship | Unicycle
Frequently Asked Questions (FAQ)
What are the primary technical specifications of the MR60-M?
The MR60-M is a 180° outbound welding injection molded 3PIN connector with a rectangular arrangement, commonly used as standard parts for lithium power connections.
Can this connector be used for wire-to-wire connections?
Yes, it is specifically designed for wire-to-wire connection scenarios, particularly between controllers and lithium batteries.
Does the MR60-M come with a rear cover?
The MR60-M features an optional rear cover depending on your specific assembly requirements.
What are the environmental restrictions for this product?
It is recommended not to use the connector in locations with high temperature or high humidity to ensure performance and longevity.
What should I pay attention to during installation?
Avoid applying external forces to the connector while in use and be extremely careful when opening the package to prevent terminal deformation or bending.
What is the main application range for the MR60-M?
It is widely used in electric vehicles, UAVs, solar lamps, balancing cars, electric scooters, and various remote-controlled vehicles or ships.
